AFFICHEUR LCD 4 1/2 DIGITS 5VOLTS

DPM, LCD, 4.5DIGIT, 5V
Supply Voltage Range:4.75V to 5.25V
No. of Digits / Alpha:4.5
Display Size:64.77mm x 32.26mm
Panel Cutout Height:22.3mm
Panel Cutout Width:53.8mm
Operating Temperature Range:0°C to +50°C
Display Technology:LCD
External Depth:10.9mm
External Length / Height:21.3mm
External Width:53mm
Operating Temperature Max:50°C
Operating Temperature Min:0°C
Accuracy:± 2 counts
Bezel Height:23.4mm
Bezel Width:55mm
Character Height:10.2mm
Material:Polycarbonate
No. of Pins:12
Pitch Spacing:2.5mm
Range:± 2V / ± 20V
Row Pitch:45.7mm
Sample Rate:2.5 samples/sec.
Supply Voltage:5.0V
